Model NO.: CQ-S1150T-1540
Type: Video Camera
Sensor: CMOS
HDMI Format: 1080P
Horizontal Resolution: 540tvl
Kind: Autofocus Lens
Feature: Waterproof / Weatherproof, High Definition, Mini Size
Effective Distance: â‰§30m
Sensor Size: 1/3 inch
Remote Control: With Remote Control
Resolution: 640X512
Thermal Lens: 35mm
Eo Lens: 4.3-129mm
Magnification: 30X
Interface: RS422 / Ttl / Lvttl
Lrf: 3km
Transport Package: Carton
Trademark: CQ or customized
Origin: Zhejiang
Production Capacity: 500set/Month
CQ-S1150T-1540 2-axis 3-sensor target positioning gimbal integrates a semiconductor laser rangefinder(max. range of 3km and accuracy of less than 2 meters), a 640Ã—512 high-resolution infrared camera, a 30x optical zoom EO camera and a high-stability precision platform frame.

It can work day and night and complete such tasks as patrol, security and search and rescue. With long-range of image capture capability, it can also conduct location to target of interest. 1080P full HD video is also capable of outputing EO & infrared videos in real time.

1. Advanced image processing algorithms can offer high-resolution, clearly contoured and wide-range dynamic images of temperature. Targets are easily visible due to clear display of slight temperature differences;
2. 4x digital zoom, 8 kinds of pseudo-color bands, stronger scene adaptability;
3. Rich OSD information, real-time display of operating status, safer, more reliable and convenient;
4. 30 times optical zoom, long-range image acquisition, more secure;
5. 1080p image compression storage, with 32G capacity memory card, higher image acquisition ability;
6. Highly integrated structural design, more reliable industrial-grade chips, steady operation even in harsh environments, stronger environmental adaptability;
7. Compared with large cameras of the same level, it is small in size, light in weight, diverse in functions, convenient to carry, safer and easier to operate;
8. High-precision gyro-stabilization design ensures stable images, operational reliability and smoothness of image capture;
9. Three modes: locking the head direction, weak following the direction of the motor head and vertical down of the lens for free switching, handle with ease;
10. Supports multiple communication interface as FE(fast ethernet), TTL and LVTTL, strong compatibility with varied UAVs.

Model CQ-S1150T-1540
Detector Uncooled focal plane
Infrared Camera Detector Resolution 640Ã—512
Focal Length 35mm
FOV 12 °Ã—10 ° ( ±5%)
Pseudo Color 8 types
Digital Zoom 1 ~ 4X continuous zoom
EO Camera Resolution 1920Ã—1080
Focal Length 4.3 ~ 129mm
FOV 63.7 ° ~ 2.3 °
Optical Magnification 30x
Fog Penetration Yes
Laser Rangefinder Wavelength 1540nm
Range â‰¥3Km (visibilityâ‰¥15km)
Ranging Accuracy â‰¤2m
Servo Platform Azimuth Angle 360 °Ã—n
Pitch Angle -120 ° ~ +90 °
Stability Accuracy â‰¤0.1mard (1Ïƒ)
Maximum Angular Velocity azimuth â‰¥ 60 °/s, pitch â‰¥60 °/s
Maximum Angular Acceleration azimuth â‰¥100 °/s ², pitch â‰¥100 °/s ²
Angular Position Accuracy â‰¤5mard(1Ïƒ)
System Parameters Boot Preparation Time â‰¤30s
Supply Voltage 20V ~ 36V DC
Power Consumption â‰¤25W (average)
Weight â‰¤1Kg
Measurement â‰¤155mm Ã— 180mm
Positioning Accuracy â‰¤30m (300m)
Interface Control Interface RS422 / TTL / LVTTL
Video Interface Gigabit network
Storage Interface 1ch 32G TF card (max. Support 128G)
Image Storage .avi format
Environmental Adaptability Operating Temp. -20 °C ~ +55 °C (-40 °C optional)
Storage Temp. -40 °C ~ +60 °C
Rainproof Can fly in light and moderate rain
