Model NO.: CTS-50
Max Diameter of Workpiece: <500mm
Mass Scope of Workpiece: <900kg
Type: Impact Testing Machine
Accuracy Grade: 0.5
Load Way: Mechanical Load
Loading Method: Static Load
Display: Computer
Control: Computer Control
Weight: 100-500Kg
Power Source: AC220V
Oil Cylinder Position: No
Test Method: Impact Specimen Notch Projector
Test: Impact Specimen
Name: Projector
Function: Check The Samples of Impact Test
Parameter: 2mm V or U Shape
Control Type: Manual or Hydralic
Transport Package: Wooden Case
Specification: CTS
Trademark: HL
Origin: Shanghai
HS Code: 9024109000
Profile projector for 2 mm V Notch / Charpy impact test sample verifying equipment

Product Description

2mm metal Impact Specimen Notch Projector
1. Application CTS-50 is a kind of special projector, which amplifies and projects the U or V-shaped profiles of the measured parts to the screen to check their profiles and shapes with high accuracy utilizing the optical projection method. It is widely used to check the U and V-shaped notch of the impact specimen with the features of easy operation, simple structure, direct inspection and high effectiveness.
Product Parameters

Diameter of the Screen

200mm

Magnification of the instrument

50X

Objective magnification

2.5X

Working table square shape

1 10x125mm

Diameter of round worktable

90mm

Diameter of working screen

70mm

Stroke of working table

Longitude: ± 10mm,Latitude: ± 10mm,
Rise and fall: ± 12mm

Eye-field diameter

3.8mm

Working distance

22.89mm

Scope of revolving of the worktable

360 °

Power supply

220V, 60HZ, 150W

Dimension

515Ã—224Ã—603mm

Light source(tungsten halogen lamp)

12V, 100W

Weight

18kg

HUALONG TEST INSTRUMENTS CO., LTD,
HUALONG Established on 1993, is a leading specialist manufacturer in China.We has more than 10 branch offices set around China and our agents have been established abroad in AmericaEurope, Japan, Spain, Malaysia, Thailand, etc.Our machines are all designed for Quality Control by testing material's mechanical properties. Over the past 20years,We has more than 420 types and all the machines can be classified to several series, such as tensioncompression, shear, bend, impact,fatigue etc.
All the products are widely used for various mechanical physical performance tests of metal, non-metal,
