Model NO.: LD-P-10001A
IR Resolution: 640*512
Laser Rangefinder Wavelength: 1535+/-5nm
Storage Temp.: -20~50degree
Warranty: 1 Year
Weight: 1.1kg
Size: 115mmÃ—134mm
Transport Package: Carton
Trademark: LEADIR
Origin: Shaanxi
Production Capacity: 500PCS/Year
Product Description
The drone's visual navigation equipment uses a two-axis, dual-frame servo stabilization platform and is equipped with sensors such as a high-definition visible light camera, an uncooled infrared thermal imager, a laser rangefinder, and a video tracker. It can achieve all-weather search, tracking, ranging, and positioning for medium and short-range targets.
Product Functions

-Equipped with high-definition visible light video and real-time infrared monitoring imaging capabilities
-Equipped with laser ranging functionality
-Equipped with gyro stabilization capabilities
-Capable of real-time output of line-of-sight frame angle position and line-of-sight angular velocity
-Capable of stable tracking of ground and aerial targets
-Equipped with AI target detection functionality
-Capable of searching and scanning designated areas
-Equipped with azimuth and elevation tracking capabilities
-Capable of image output switching
-Output images can overlay relevant information
-Equipped with target position calculation functionality
-Equipped with visual navigation functionality

Product Advantages

-AI intelligent design reduces manual interventionVisual navigation technology is resistant to GPS interference
-80 µrad stabilization accuracy
-Airtight and nitrogen-filled design to prevent fogging and maintenance-free operation
-Capable of operating under harsh conditions from -40 °C to +60 °C
-Excellent electromagnetic compatibility design
-Strict quality control

Product Parameters

Main Performance Specifications:

a) Rotation Range

Azimuth: ±150 º
Elevation: -110 ° to +50 ° (horizontal is 0 °)

b) Maximum Steady Rotation Angular Velocity

Azimuth: â‰¥60 °/s
Elevation: â‰¥60 °/s

c) Angular Position Accuracy

Azimuth: â‰¤0.3 ° (1Ïƒ)
Elevation: â‰¤0.3 ° (1Ïƒ)

d) Stability Accuracy

Azimuth: â‰¤80 µrad (1Ïƒ) (1 º/2Hz, 2 º/1Hz)
Elevation: â‰¤80 µrad (1Ïƒ) (1 º/2Hz, 2 º/1Hz)

e) Visual Navigation Matching Accuracy

Visual navigation matching accuracy: better than 2 pixels

f) High-Definition Visible Light Camera

Focal Length: 8mm/16mm (optional)
Field of View (16mm): 19.01 ° Ã— 10.76 ° ( ±5%)
Resolution: 1920 Ã— 1080 pixels
Detection Range (16mm):
Person: â‰¥1 km
Vehicle: â‰¥2 km (visibility â‰¥20 km / relative humidity 80%)
Recognition Range (16mm):
Person: â‰¥0.5 km
Vehicle: â‰¥1 km (visibility â‰¥20 km / relative humidity 80%)

g) Infrared Detector

Detector Type: Long-wave uncooled
Pixel Count: 640 Ã— 512
Focal Length: 25mm/35mm (optional)
F#: 1.0
Field of View (35mm): 12.52 ° Ã— 10.03 ° ( ±5%)
Detection Range (35mm):
Person: â‰¥0.6 km
Vehicle: â‰¥1.2 km (visibility â‰¥20 km / relative humidity 80%)
Recognition Range (35mm):
Person: â‰¥0.3 km
Vehicle: â‰¥0.6 km (visibility â‰¥20 km / relative humidity 80%)

h) Laser Rangefinder

Operating Wavelength: 1535 ±5 nm (eye-safe)
Ranging Distance: â‰¥2 km
Ranging Accuracy: ±2 m
Repetition Frequency: â‰¥5 Hz

i) Power Supply and Weight

Power Supply: Typical DC 24V, compatible with DC 18V to 36V
Rated Power Consumption: â‰¤20W
Peak Power Consumption: â‰¤50W
Weight: â‰¤1.3 kg
Product Application

Image Effect

About us

Xi'an Zhongke Lead IR-Tech Co., Ltd established in 2015, is a R&D enteprise based on intelligent electro-optical equipment and infrared thermal imaging technology, incubated by Xi'an Institute of Optics and Precision Mechanics of China Academy of Sciences.Since foundation,Lead IR-Tech has been dedicated to the R&D of infrared imaging and measurement technology since foundation,with a strong emphasis on developing intelligent infrared photoelectric devices. It has grown into a well-known supplier of infrared imaging and measurement equipment in China.
