Model NO.: LC221
Formula: FEP
Material: FEP
Usage: Engineering Plastics
Plastic Properties After Heated: Thermoplastic Resin
Plastic Forming Method: Injection
Color: Clean
Product Features: Self-Lubricating, Heat Resistance, Flame Retardant, Radiation-Resistant
Transport Package: Box
Specification: 20KG/BOX
Trademark: HUIJU
Origin: China
Package Size: 85.00cm * 40.00cm * 25.00cm
Package Gross Weight: 25.000kg
Product Description: FEP High-Speed Extrusion Series
Application Fields: Wire and cable industry (RF cables, magnet wire, communication cables), fluororesin sleeves, high-temperature electronic wires, communication cables, power cables, computer cables, tubing
Application in Industries: Household appliances, computers, communication, photovoltaic
Relative Density: 2.12-2.18 g/cm³
Melt Flow Rate: 3-4 g/10min (LC208), 6-8 g/10min (LC209), 4-6 g/10min (LC210), 9-11 g/10min (LC211), 13-17 g/10min (LC215), 18-22 g/10min (S200)
Melting Point: 270±5 °C
Tensile Strength: ≥18 Mpa
Elongation at Break: ≥275 Percentage
Shore hardness: 58 R
Coefficient of Friction: 0.3
Continuous Use Temperature: 200 °C
Heat Deflection Temperature: 47 °C (1.82 Mpa)
Coefficient of Thermal Expansion: 8-15 (-10^-5/°C)
Volume Resistivity: 10^16-10^18 Ω.cm
Dielectric Strength: 20 KV (3.2mm)
Relative Permittivity: 2.1-2.3 (10³HZ)
Dielectric Loss Tangent: <0.0005 (10^6HZ)
Production Notes: Dry at 120℃ for 2 hours before production, equipment must be thoroughly cleaned, industrial use only.
Company Name: Ningbo Polymer Materials Co., Ltd
Main Plastic Raw Materials: General-purpose plastics, Engineering plastics, Modified plastics, Elastomer plastics, Specialty engineering materials, Modified toughening compatibilizers.
General Purpose Plastics List: ABS, CPE, EAA, EVA, LDPE, LLDPE, PET, PP, PVC.
Engineering Plastics List: PA6, PA66, PC, PC/ABS, PCTG, PETG, POM.
Elastomer Plastics List: EMA, EMMA, CPE, POE, POP, SBS, SEBS, TPE, TPEE, TPU, TPV.
Special Engineering Plastics List: COC, CPVC, LCP, PA12, PEEK, PEI, PES, PTFE, SMMA.
Toughening Compatibilizer List: Grafted PP, Grafted PE, Grafted EVA, Grafted POE, Grafted SEBS.
Modified Alloy Plastic List: PP Glass Fiber Reinforced, PA Glass Fiber Reinforced, ABS/PA, ABS/PBT, ABS/PC, ASA/PC, PA66/PTFE, PA66/C/PTFE, PA66/F/PTFE, PA12 Eyeglass Frames/Legs Special Material for Cost Reduction.
