Model NO.: HF105D
Size: 59 X 48.4 X 85.7mm
Weight: 110g
Working Temperature: -20 ~ 50 Degree
Equivalent Digital Zoom Rate: 8X
Tracking Speed: ±32 Px / Field
Transport Package: Packing
Specification: HF105D
Trademark: HFHW
Origin: China
Production Capacity: 2000
Product Description

The HF105D Intelligent 4K Full-Color Night Vision Dual-Sensor Micro Pod carries a 4K resolution camera empowered with the AI-ISP full-color night vision imaging engine, which can provide a good full-color night observation performance even in extremely low-light environments such as night time or confined spaces. The HF105D also features a long-wave infrared thermal camera, which can capture thermal images. The Z-2Mini has AI multi-object detection and tracking function. The pod can intelligently identify the persons and vehicles in the image, and constantly tracking one of them.

With a high accuracy 3-axis nonorthogonal gimbal, the HF105D can be mounted hether downward or upward. With the Dragonfly software, users can watch the image from the camera and control the pod real-timely on a computer. With the customized QGC software, all the functions of the pod can be achieved in conjunction with an open source autopilot.

Product Parameters

General
Product Name HF105D
Dimensions

59 x 48.4 x 85.7mm

Weight

110g

Operating Voltage 10 ~ 26.4VDC
Power

6.5W (AVG) / 20W (Stall)

Mounting Downward / Upward
Gimbal
Gimbal Type 3-axis Nonorthogonal Mechanical Stabilization
Angular Accuracy ±0.01 °
Controllable Range Pitch: -135 °~+100 °, Roll: ±50 °, Yaw: ±150 °
Max Controllable Speed ±200 °/s
Fixed Camera
Image Sensor 1/2.8-inch CMOS, Effective Pixels: 8.29M
Lens

Actual Focal Length: 6.0mm (Equivalent focal length: 40.6mm)

Aperture: f/1.0

HFOV: 54.7 °

VFOV: 30.2 °

DFOV: 63.2 °

Resolution 3840(H) x 2160(V)
Pixel Size 1.45Î¼m(H) x 1.45Î¼m(V)
Equivalent Digital Zoom Rate 8x
Object Detection Distance EN62676-4:2015

Person[1]:175m

Light vehicle[2]:230m

Large vehicle[3]:491m

Johnson Criteria

Person:2069m

Light vehicle:6345m

Large vehicle:13517m

Object Identification Distance EN62676-4:2015

Person:35m

Light vehicle:46m

Large vehicle:98m

Johnson Criteria

Person:517m

Light vehicle:1586m

Large vehicle:3379m

Object Verification Distance EN62676-4:2015

Person:18m

Light vehicle:23m

Large vehicle:49m

Johnson Criteria

Person:259m

Light vehicle:793m

Large vehicle:1690m

Thermal Camera
Thermal Sensor Uncooled VOx Microbolometer
Lens

Actual Focal Length: 10.0mm (Equivalent focal length: 112.7mm)

Aperture: f/1.0

HFOV: 17.5 °

VFOV: 13.2 °

DFOV: 21.8 °

Resolution 256(H) x 192(V)
Pixel Size 12Î¼m(H) x 12Î¼m(V)
Spectral Band 8~14Î¼m
Sensitivity (NETD) <50mk@25 ºC
Object Detection Distance Johnson Criteria

Person:417m

Light vehicle:1278m

Large vehicle:2722m

Object Identification Distance

Person:104m

Light vehicle:319m

Large vehicle:681m

Object Verification Distance

Person:52m

Light vehicle:160m

Large vehicle:340m

AI Multi-object Detection & Tracking
Object Size 16x16 ~ 128x128 px
Object Identification Delay < 40ms
Tracking Speed ±32 px / field
Tracking Deviation Refresh Rate 30Hz
Tracking Deviation Output Delay â‰¤ 5ms
Image & Video
Image Format JPEG
Maximum Image Resolution 3840 x 2160
EXIF Shooting point coordinate
Video Format MP4
Maximum Video Resolution

Stream: 1920 x 1080 @30fps

Recording: 3840 x 2160 @30fps

Stream Encode Format H.264,H.265
Stream Network Protocol RTSP
Storage
Supported SD Cards Supports a U3/V30 or above MicroSD card with a capacity of up to 256GB
Environment
Operating Temperature -20 ºC~50 ºC
Storage Temperature -40 ºC~60 ºC
Operating Humidity â‰¤85%RH (Non-condensing)

[1] Reference dimension of person: 1.8x0.5m. Critical dimension under Johnson criteria is 0.75m.

[2] Reference dimension of light vehicle: 4.2x1.8m. Critical dimension under Johnson criteria is 2.3m.

[3] Reference dimension of large vehicle: 6.0x4.0m. Critical dimension under Johnson criteria is 4.9m.

Detailed Photos
