Model: Zcjk-180
Display: 15-Inch Display
Power Supply: 220V 50Hz
Middle Frequency: 1.14kHz,1kHz,3kHz,4kHz
Waveform: Square Wave, Sine Wave, Triangle Wave, Spike Wave
Timing Function: 0min~99min Adjustable
Music Mode: Music Mode Is Optional
Weight: 120kg
Transport Package: Wooden Box
Specification: 2*2.2*1.85M
Trademark: zcjk
Origin: China
Product Description

gastrointestinal middle frequency therapy device:
Gastrointestinal treatment equipment uses alternating current with a frequency of 1.14kHz-4kHz, which acts on specific parts of the human body through specific electrodes. The carrier is a medium-frequency current with strong penetrating power to send the modulated wave into the human body to achieve deep rehabilitation treatment
Main Indications

Superficial erosive gastritis, gastric ulcer atrophic gastritis, acute and chronic gastroenteritis
Medium frequency current can excite the thick fibers of peripheral nerves and achieve analgesic effect Abdominal pain, bloating, diarrhea, constipation
Medium frequency modulation wave or interference wave can cause muscle contraction and promote the return of blood and lymph Abdominal pain, bloating, diarrhea, constipation
ium frequency current can expand the gap between cells and tissues, loosen the adhesion of connective tissue fibers, muscle fibers, and nerve fibers
How to use

No.
Carrier frequency
(Hz)
Modulation Waveform
Pulse width
(Î¼s)

Modulation frequency
(Hz)
Treatment time (min)
1 1.14kHz sine wave 439Î¼s 0-150Hz 20
2 1.14kHz sine wave 439Î¼s 0-150Hz 20
3 1.14kHz sine wave 439Î¼s 0-150Hz 20
4 1kHz Sine wave, square wave, spike wave 500Î¼s 0-150Hz 20
5 3kHz Sine wave, square wave, spike wave, triangle wave 167Î¼s 0-150Hz 20
6 4kHz Sine wave, square wave, spike wave, triangle wave 125Î¼s 0-150Hz 20
FAQ

No display after power on:
Fuse blown: Fuse model: F4AL250 V dia5x20mm
Power supply failure: Check whether the power supply is properly connected
Network power supply voltage is too high: The power supply voltage is stable between 220V ± 22V
Machine failure
No current output:
Output line broken: The two core pins in the output line connector should be connected to the two clamps respectively. Remove the output line and use the resistance range of the multimeter to check whether it is connected. If it is not connected or the resistance is greater than 1Î©, it should be considered abnormal. Solution: Repair or replace the output line.
